ZY-10 Self-lubricating bearings
It’s made of high quality low-carbon steel plate, sintered porous bronze as its interlayer and the compound of PTFE material and Pb as its surface. It can offer the properties of good self-lubricating anti-abrasion, low-friction, fully develop the advantages of metal and multi-element polymer.It's used in steel metallurgical industry, such as those used in roller grooves of successive casting machines, cement grout pump and spiral conveyers for cement etc.
- PTFE/Pb Composition, 0.01-0.03mm, anti-abrasion material, which will form a lubricating film during operation.
- Sintered Bronze powder layer, 0.2-0.35mm, which further strengthen the combination of the steel plate and PTFE layer and transfer the heat more quickly.
- Low carbon steel backing, bear high load transfer heat.
- Copper/Tin plating layer, anti-corrosion.
Material Structure
| Max Load | Static load | 250N/mm2 | Friction coefficient | 0.03~0.20 | ||
|---|---|---|---|---|---|---|
| Low-speed Rotation | 140N/mm2 | max linear velocity | dry friction | 2m/s | ||
| Rotation、Oscillation | 60N/mm2 | Hydrodynamic lubrication | >2m/s | |||
| Max PV (Dry Friction) |
Short-term operation | 3.6N/mm2．m/s | Thermal conductivity | 42W(m．K)-1 | ||
| Continuous operation | 1.8N/mm2．m/s | Coefficient of thermal expansion | 11x10-6/K | |||
| Operation Temp. | -195℃~＋280℃ | |||||
Appliation
- Working under oilless or minim oil state, maintenance free or just need a little maintenance.
- Resist Abrasion, low coefficient of friction long operating life.
- Operating in -195℃～+280℃
- Good mending, low-noise, non-pollution
- Thin wall, light, which can reduce the machine to small
- Forming a transferred film during operation to protect shaft
- Low demand to the shaft even no surface hardness treatment, which lower the cost of the mating components
- No absorption to water/oil, small coefficient of Thermal emption, good thermal conductivity and size stability
- The back of the steel strip can be plated with various metal, anti-corrosion The products now are used in sliding components of different machines, such as auto machines, piston pump, gear pump, textile machine, auto-sides machine, Injection Machine, sports Machine office equipment etc.
